DeviceNet - Design
13.4 Electrical data
Connections:
"Multi-pole": 1 x M16 x 1.5 cable gland / size22 with multi-pole connection
(M12plugaccordingtoIEC61076-2-101,5-pole)forDeviceNetbus
and power supply, cable length approx. 80 cm
1 x M16 x 1.5 cable gland/size19 - connection option for external
initiator(sealedwithdummyplug,removethesebeforeuse)
Power supply: 11…25VDC(accordingtospecication)
Max. power consumption: <200mAat24VDC(200msafterswitchingonofthevalves)
Input / proximity switches (external initiator: S4 in):
Power supply: via DeviceNet power supply - 10%
Current carrying capacity sensor
supply: max. 30 mA
Short-circuit protection
Design: DC 2- and 3-wire,
Normally open contact, PNP output
Input current 1 signal: I
Sensor
> 6.5 mA, limited internally to 10 mA
Input voltage 1 signal: U
Sensor
> 10 V
Input current 0 signal: I
Sensor
<4mA
Input voltage 0 signal: U
Sensor
<5V
Inputs (from master perspective) / binary or analog feedback signals:
The recovery of the 3 valve positions reported back in binary format or the analog position signal is
described in chapter “20PositionMeasuringSystem”onpage129.
Outputs (from master perspective) / solenoid valves:
Typ.switchingcapacity: 0.9W(persolenoidvalve,for200msafterswitchingon)
Typ.continuousoutput: 0.6W(persolenoidvalve,from200msafterswitchingon)
Power consumption per
solenoid valve: 50 mA at 12 V DC
25 mA at 24 V DC
22 mA at 28 V DC
Operatingmode: Long-termoperation(100%ED)
Valve types: 6524
Central display of the switching statuses:
Power consumption from DeviceNet
at 24 V DC: approx. 42 mA with a power supply of 24 V DC per illuminated
display;
colour switching see chapter “21LEDColourAssignments”onpage
136
13.5 Safety position if the bus fails
Ifthebusfails,thesolenoidvalveisswitchedtoaprogrammablesafetyposition(default:solenoidvalvenot
energised).Forcongurationdataseechapter“13.12.1Congurationofthesafetypositionofsolenoidvalves
duringabuserror”.
