IO-Link - Design
14.4 IO-Link master / communication / conguration
IO-Link master
IO-LinkmastersareusedastheinterfacebetweenthecontrolheadsType8681(IO-Link)andthehigher-
levelcontroller.AllcommonlyusedIO-Linkmastersinaccordancewiththespecication(seechapter
“14.3”)canbeused.
The“addressing”oftheIO-LinkdevicesisdenedbytheconnectionorportontheIO-Linkmaster–Thismust
be noted when replacing the devices or master.
Communication / conguration / parametrisation
Afterthenetworkhasbeensetup(seeforexample“14.1Networkprinciple/interfaces”)andthecorrect
softwarehasbeeninstalledintheIO-Linkdevices(IODDtakingintoconsiderationtheportclass)thenetwork
isconguredusingthehigher-levelcontroller.
As described in chapter “14.1”, an IO-Link control head can also be connected in parallel to the IO-Link port
withtheBürkertCommunicator(Type8920)viatheserviceinterface(Micro-USB)ontheelectronicmodule
(see“Fig.36”onpage82).
To ensure clear communication, IO-Link devices should not be parametrised simultaneously by the higher-
levelcontroller(PLC)viatheIO-LinkmasterandwiththeBürkertCommunicator(viatheserviceinterface).
14.5 Electrical data form the control head (IO-Link)
14.5.1 Electrical connection options / interface
or
with cable glands
or
with cable glands and multi-pole connection
(M12connectioninaccordancewithIEC61076-2-101,
4-pole(portclassA)or5-pole(portclassB),
cable length approx. 15 cm
Connectionleft:  voltage,signals(IO-Linkport)
Connection right: external initiator
Fig. 35: Connection options
Connections:
Cable gland variant: 1xM16x1.5cablegland/size22–forpowersupplyandsignals(IO-Link);
only for transportation safety device sealed with dummy plugs, remove these
beforeuse)forcablediameter5...10mm,forwirecross-sections0.14...
1.5mm
2
1 x M16 x 1.5 cable gland/size19 – connection option for external proximity
switch(sealedwithdummyplug,removethisbeforeuse)
Variant multi-pole connection: 1 x M16 x 1.5 cable gland/size22 with M12 connector in accordance with IEC
61076-2-101,4-pole(portclassA)or5-pole(portclassB)forpowersupply
andsignals(IO-Link),cablelengthapprox.15cm
1 x M16 x 1.5 cable gland/size19 – connection option for external proximity
switch(sealedwithdummyplug,removethisbeforeuse)
