Service Mode / Manual override
22 SERVICE MODE / MANUAL OVERRIDE
Bydefault,thecontrolheadprovidesthefollowing(e.g.forservicepurposes):
• a magnetic manual overridewhichiseasilyaccessiblefromtheoutsideforsolenoidvalve1(2/A1)
*)
as
well as
•
a mechanical manual override accessiblewhenthehoodisopenoneachequippedsolenoidvalve–
see chapter “22.2Mechanicalmanualoverride”.
22.1 Magnetic manual override
Magnetic manual
override tool
Markings for
magnetic
manual override
Fig. 49: Magnetic manual override / magnetic manual override tool on the basis of encoded magnetic elds
Irrespective of the signal of the higher-level control, the magnetic manual override sets in the Automatic mode
theoutputofthesolenoidvalveV1
*)
electrically to an ON signal and, if control pressure is present, switches
the 2/A1 output
*)
, in manual operating status, the manual override cannot be used.
However, if the output of solenoid valve 1
*)
isactivatedbythecontrol(ONsignalfromthehigher-level
control),thisswitchingstatuscannotbesettoanOFFsignalwiththemanualoverride!
Activation/deactivation of this function is possible using the PC service program. The factory setting is
“magneticmanualoverridefunctionactive”,i.e.thefunctioncanbeused,itisnotdisabled.
The connection to the PC is made via the service interface. Details are described in the “PC Service
ProgramType8681”softwaremanualunderthe“SYSTEM/Start-up”menuoption(fortheIO-LinkandbüS/
CANopendesign,thechangeovercanbecarriedoutviatheBürkertCommunicator).
Caution!
When the magnetic manual override (solenoid valve 1
*)
) will be actuated:
•the peripheral fault bit is set on the AS interface design.
•the mode is switched to "Manual override active" for the DeviceNet design and can be read out.
•
thefeedbacksignals(valvepositionsS1-3,externalinitiator)functionaspernormaloperation.
Always observe the safety guidelines and the system statuses!
________________________
*)
bothsolenoidvalvesareactuatedsimultaneouslyforthedesignfordouble-actingactuators(seechapter“19 Special
designs”onpage127)
