cab Produkttechnik GmbH & Co KG
B - Barcode
Aztec - Code
m m
J
S l1;0,0,68,71,100
B 5, 5,0,
Aztec+EL55
,1;CAB Produkttechnik GmbH & Co KG
B 45,5,0,
Aztec+EL90
,0.6;CAB Produkttechnik GmbH & Co KG
A 1
The same barcode contents with variations on error level and dot size.
Example:
112
114
