114cab Produkttechnik GmbH & Co KG
B - Barcode Codabar
Barcode type: Codabar
Length: variable
Valid characters: numeric,
special characters: - $: /. +
and special start stop codes (A,B,C,D)
check digits: yes (Mod 16)
ratio oriented: yes
Each character of this barcode is built with 7 elements (bars and spaces), where
the spaces do not contain information. Codabar ist mostly used in medical
environments for photo laboratories and libraries. The exact specifications are
described in the Norm: EN 798. The start and stop characters are additionaly
A,B,C or D.
B[:name;]x,y,r,CODABAR[+options],height,ne,ratio;text
CR
B - Barcode field definition
[:name;] = field name
x = x - coordinate
y = y - coordinate
r = Rotation 0, 90, 180 and 270 degrees
type = Barcode type (CODABAR)
[+options] Following options are available:
+MODxx = calculation of modulo check digit (MOD 16)
+WSarea = white space area
+BARS = Prints boundary lines above and below the barcode.
+UPBAR = Prints a boundary line above the barcode
+DOWNBAR = Prints a boundary line below the barcode
+VERIFYn = Verify the barcode data. (optional barcode reader required )
+GOODBADn = Same function as +VERIFYn without checking the content.
height = Barcode height
ne = Narrow element
ratio = Ratio between narrow and wide bars.
text = Barcode data
Detailed descriptions are at the beginning of the barcode chapter.
Syntax:
