C - Cutter Parameters
The following sample requires the optional Perforation Cutter.
m m
J
O R
S e;0,0,18,18,100
T 10,14,90,5,4;Perfo
T 15,12,0,5,5;First cut is the deepest
C s
C 4
C p
A 12
This example cuts at the print start ( C s ), does a perforation cut after each label ( C p ) and cuts the
material completely after each 4th label ( C,4,0 ).
All together 12 labels will be produced. ( A 12 ) - the picture blow shows just 8 of them...
The label was defined 18 mm high on continuous material.
Example:
cut through
cut through
cut through
perforations
perforations
