cab Produkttechnik GmbH & Co KG
I -
I
mage Field Definition
m m
J
S l1;0,0,68,71,100
I:IMAGE1;10,10,0,2,2,a
;tree
A1
This example recalls the picture with the name " tree.bmp " from any memory card of the
printer and prints it resized (enlarged) by the factor 2 in x- direction and factor 2 in y
direction. Please keep in mind that enlarging pictures can have a negative influence on
the printout quality
.
Example:
240
242
