9-12
The audio in each aux bus passes through the send level and pan
controls, is processed by any real-time effects you have patched, sent
through the return level and pan controls, and then sent to the
designated main output, in stereo. This is shown in the picture below:
At each main output, all audio data from audio tracks and aux busses
that were routed to the main are mixed together and processed by the
mainÕs real-time effects. Finally, the data passes through the master
volume faders and is sent to the output port, as shown in the following
picture:
Real-time effects
Send level
Send balance
Return level
Return balance
Destination (Main output)
Right channel output volume fader
Left channel output volume fader
Level meters
Real-time effects
