Canon MF726Cdw - Page 120

J
No.
Symbol Name Relay connector J No. Symbol Name Remarks
J904 UN13 Main Controller PCB J1401 J1404 PS701 CIS Unit Homeposition Sensor
J922 UN13 Main Controller PCB J922 SP1 Speaker MF728Cdw /
727Cdw /
726Cdw /
725Cdn
J902 UN13 Main Controller PCB J1003 J1003 SL4 ADF Pickup Solenoid
■ 4/5
J201
J210
J211
J210
J207
J206
J205
J204
J203
J202
J2001
J213
J2005
J207
J209
J208
J653
J140
J2002
J2003
J206
J209
J208
J2004
J910
J1005
J No. Symbol Name Relay connector J No. Symbol Name Re-
marks
J140 UN1 DC Controller PCB J201 UN2 Driver PCB
J202 UN2 Driver PCB J2004 M5 Pickup Motor
J203 UN2 Driver PCB J2005 M3 Registration Motor
J204 UN2 Driver PCB J2003 M2 Developing Motor
J205 UN2 Driver PCB J2001 M4 Fixing Motor
4. Disassembly/Assembly
112
