Canon MF726Cdw - Overview

Overview
Adjustment required in the field service works when following parts are replaced. The parts are classified by 3 function blocks.
Category Parts Reference
Document Exposure /
Feed System
ADF Units “After Replacing the ADF Units” on page 226
Reader Units “After Replacing the Reader Unit” on page 227
Scoopup Sheet Holder “After Replacing the Scoopup Sheet Holder” on page 233
Reader Upper Cover Unit “After Replacing the Reader Upper Cover Unit” on page 230
CIS Units “After replacing CIS units” on page 232
Controller System Main Controller PCB “Main Controller PCBs” on page 234
DC Controller PCB “DC Controller PCB” on page 238
Laser Exposure Sys-
tem
Laser Scanner Unit “After Replacing the Laser Scanner Unit” on page 239
