Canon MF726Cdw - I;O

■ JAM
Jam code display screen
Up to 20 Jam codes and detailed codes for system errors can be shown.
■ CCD
COPIER > DISPLAY > CCD
Item Description
TARGET-B
Title Shading target value (B)
Details To display the shading target value of Blue.
Continuous display of 128 (minimum) or 384 (maximum) is considered a failure of the CIS Unit.
Use case At scanned image failure
Adj/set/operate method N/A (Display only)
Display/adj/set range 128 to 384
Default value 269
Related service mode COPIER > ADJUST > CCD > DFTAR-B
TARGET-G
Title Shading target value (G)
Details To display the shading target value of Green.
Continuous display of 128 (minimum) or 384 (maximum) is considered a failure of the CIS Unit.
Use case At scanned image failure
Adj/set/operate method N/A (Display only)
Display/adj/set range 128 to 384
Default value 270
Related service mode COPIER > ADJUST > CCD > DFTAR-G
TARGET-R
Title Shading target value (R)
Details To display the shading target value of Red.
Continuous display of 128 (minimum) or 384 (maximum) is considered a failure of the CIS Unit.
Use case At scanned image failure
Adj/set/operate method N/A (Display only)
Display/adj/set range 128 to 384
Default value 263
Related service mode COPIER > ADJUST > CCD > DFTAR-R
TARGETBW
Title Shading target value (BW)
Details To display the shading target value at B&W jobs.
Continuous display of 128 (minimum) or 384 (maximum) is considered a failure of the Main Controller PCB.
Use case At scanned image failure
Adj/set/operate method N/A (Display only)
Display/adj/set range 128 to 384
Default value 276
Related service mode COPIER > ADJUST > CCD > DFTAR-BW
I/O
■ R-CON
COPIER>IO>R-CON
Ad-
dress
BIT Description Remarks
P001 0 Display sensor status (Document end sen-
sor)
While the screen is open, the values are updated periodically (with an
interval of 1 second).
1 Display sensor status (Document sensor)
