COPIER > ADJUST > SCNR
Item Description
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -1023 to 1023
Default value 0
SUB-S-K1
Title Adjustment of emitting position 2 (Bk) in the vertical scanning direction
Details To adjust the Bk-color emitting position 2 in the vertical scanning position.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -1023 to 1023
Default value 0
SUB-S-Y2
Title Adjustment of emitting position 3 (Y) in the vertical scanning direction
Details To adjust the Y-color emitting position 3 in the vertical scanning position.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -1023 to 1023
Default value 0
SUB-S-M2
Title Adjustment of emitting position 3 (M) in the vertical scanning direction
Details To adjust the M-color emitting position 3 in the vertical scanning position.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -1023 to 1023
Default value 0
SUB-S-C2
Title Adjustment of emitting position 3 (C) in the vertical scanning direction
Details To adjust the C-color emitting position 3 in the vertical scanning position.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -1023 to 1023
Default value 0
SUB-S-K2
Title Adjustment of emitting position 3 (Bk) in the vertical scanning direction
Details To adjust the Bk-color emitting position 3 in the vertical scanning position.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -1023 to 1023
Default value 0
MAI-S-Y0
Title Adjustment of scan time 1 (Y) in the horizontal scanning direction
Details To adjust the Y-color scan time 1 in the horizontal scanning direction.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -511 to 511
Default value 0
MAI-S-M0
