COPIER > ADJUST > SCNR
Item Description
Default value 0
MAI-S-Y2
Title Adjustment of scan time 3 (Y) in the horizontal scanning direction
Details To adjust the Y-color scan time 3 in the horizontal scanning direction.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -127 to 127
Default value 0
MAI-S-M2
Title Adjustment of scan time 3 (M) in the horizontal scanning direction
Details To adjust the M-color scan time 3 in the horizontal scanning direction.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -127 to 127
Default value 0
MAI-S-C2
Title Adjustment of scan time 3 (C) in the horizontal scanning direction
Details To adjust the C-color scan time 3 in the horizontal scanning direction.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -127 to 127
Default value 0
MAI-S-K2
Title Adjustment of scan time 3 (Bk) in the horizontal scanning direction
Details To adjust the Bk-color scan time 3 in the horizontal scanning direction.
Use case When replacing the Laser Scanner Unit, enter the value written on the label included in the package of
the Laser Scanner Unit
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -127 to 127
Default value 0
■ PANEL
COPIER > ADJUST > PANEL
Item Description
TOUCHCHK
Title Correction of coordinate position of Touch Panel
Details To correct the coordinate on the Touch Panel.
Use case When a problem occurs to the coordinate position in such a way that a position different from the one
that was touched reacts.
Adj/set/operate method Touch the "+ (plus)" mark displayed on the Touch Panel with something with a sharp tip such as a
pen.
TOUCHCHK-R
Title Flag to check whether the correction of coordinates on the Touch Panel was properly executed
Details To check whether the correction of coordinates on the Touch Panel was properly executed. 1 is
displayed when the correction of coordinates is properly executed. 0 is displayed when it fails.
Use case When executing the correction of coordinates after replacing the Touch Panel with a new one
Display/adj/set range 0 to 1
0: Not executed
1: Executed
Default value 0
8. Service Mode
276
