THS – FI022GB2K8v3 --- VI - APPENDICES
94
Motor control card 00208MDL 1 18943
Motor control card 00208MDT 1 19946
Remote control card 00208RCU 1 18945
Auxiliary power supply unit 1 23400
Power supply card 00208MAG 1 23240
Picket-Fence bar code reader (code with vertical bars) 1 17823
Step-Ladder bar code reader (code with horizontal bars) 1 18700
Options
Description Quantity Code
RS 485 interface 1 17828
Remote control module for Conveyor Control System 1 21559
Remote control module for Control Power Box 1 21560
115/230Vca Transformer Box 1 23181
400/230Vca Transformer Box 1 23182
Protection against high-pressure water cleaning 1 24775
Ethernet Module 1 29756
Accessories
Description Quantity Code
Set of quality control test samples (AISI 420 steel (ferromagnetic) and AISI 316 Stainless steel) High
sensitivity
1 18711
Set of quality control test samples (AISI 420 steel (ferromagnetic) and AISI 316 Stainless steel) - Low
sensitivity
1 22605
Sample with a ø 0.8 mm in AISI 420 steel sphere (ferromagnetic) 1 18124
Sample with a ø 1.0 mm in AISI 420 steel sphere (ferromagnetic) 1 18125
Sample with a ø 1.2 mm in AISI 420 steel sphere (ferromagnetic) 1 18126
Sample with a ø 1.5 mm in AISI 420 steel sphere (ferromagnetic) 1 18127
Sample with a ø 2.0 mm in AISI 420 steel sphere (ferromagnetic) 1 18128
Sample with a ø 2.5 mm in AISI 420 steel sphere (ferromagnetic) 1 18129
Sample with a ø 3.0 mm in AISI 420 steel sphere (ferromagnetic) 1 18130
Sample with a ø 3.5 mm in AISI 420 steel sphere (ferromagnetic) 1 18131
Sample with a ø 4.0 mm in AISI 420 steel sphere (ferromagnetic) 1 20251
Sample with a ø 4.5 mm in AISI 420 steel sphere (ferromagnetic) 1 20252
Sample with a ø 5.0 mm in AISI 420 steel sphere (ferromagnetic) 1 22056
Sample with a ø 5.5 mm in AISI 420 steel sphere (ferromagnetic) 1 22057
Sample with a ø 6.0 mm in AISI 420 steel sphere (ferromagnetic) 1 22058
Sample with a ø 6.5 mm in AISI 420 steel sphere (ferromagnetic) 1 22059
MDScope 1 19795
MDCAD 1 27185
THS REPORT 1 27184
RS232/RS485 converter 1 21540
THS/PH
Validity: revision 1.102, 12/04/2001
Spare parts
Description Quantity Code
Control panel 1 18657
SPM module 1 21853
Deflector 1 18743
Infeed conveyor 1 16332
Support assembly 1 16043
Cable connecting the probe to the power supply unit 1 18938
Power supply unit 1 18744
Power supply card 00208ALM20 1 18939
Included sample - Stainless steel (ø0.3mm sphere) 1 17052
Included sample - Iron (ø0.3mm sphere) 1 17051
Included sample - Blank 1 16793
Short discharge conveyor 1 16335
Long discharge conveyor 1 19803
Deflector cover 1 16344
Deflector white basis in PETG 1 16333
Deflector flap position sensor 1 15286
Flap actuator 1 23541
Steel deflector flap 1 23542
Options
Description Quantity Code
RS 485 interface 1 17828
Accessories
Description Quantity Code
MDScope 1 19795
