Transit speed
Generally-applied setting Programming
parameters
Meaning
THS/STD THS/SL THS/3F THS/M THS/G THS/PH
BS
Transit speed
2 - 250m/’ 2 - 250m /’ 2 - 250m /’ 20 - 70m/’ 2 - 250m /’ 2 - 250m /’
BL
Minimum transit speed
2 m/’ 2 m/’ 2 m/’ 20 m/’ 2 m/’ 20 m/’
BM
Maximum transit speed
250 m/’ 250 m/’ 250 m/’ 70 m/’ 250 m/’ 250 m/’
KT
transmission constant of
the motor reducer unit
KT = transit speed .
motor driver frequency
_ _
DI
Diameter of roller
DI = ø roller + 2 x (thickness of belt)
_ _
KE
Encoder constant
(impulses per revolution)
0-1000 impulses per revolution _ _
MI
Maximum motor
operating frequency
60-100 (Hz) - -
CU
Maximum motor current
consumption
0.000 - 7.000 A - -
The programming parameters must be properly defined depending on the type of installation.
Fixed-speed application,
without inverter card,
without encoder (KT=0.000,
KE=0)
V
BS should be assigned the true value of the transit speed.
Fixed-speed application,
with MDT card but with
encoder (KT=F, KE=0)
V
BS should be assigned the true value of the transit speed.
Variable-speed application,
with encoder, without
inverter card
V
speed detected by the encoder. The speed limits (BL e BM) must be
selected.
The KT parameter is 0.000.
Assign to the KE parameter the number of pulses per revolution of the
encoder.
Assign to the DI parameter the value of the diameter of the motor roller (see
table above)
