THS – FI022GB2K8v3 --- V - MAINTENANCE
67
Remote Possible settings Standard setting Parameter
Belt lower sp.
BL
See below -
Global
Description Models
Minimum transit speed
This parameter appears only if the variable speed inverter module (MDL) is fitted (KT > 0.000) or an encoder is
connected (KE>0). In case an encoder without MDL is fitted, the range is 2 < BL < 250 m/min. In case MDL is fitted
then 20KT < BL < BM.
The parameter is not applicable in case of fixed-speed, MDT card fitted (KT=F) or no conveyor belt.
With MDL: select the minimum operating speed
If MDL is fitted, BL
≥
20KT; Alteration of parameter KT results in automatic assignment of BL=20KT.
All models,
except THS/G
Remote Possible settings Standard setting Parameter
Belt Speed
BS
2 – 250 m/min. -
Related to the current
product
Description Models
Transit speed
In case of conveyor belt with fixed speed or models without conveyor belt, insert the real value of the product transit
speed.
If KE>0 and KT=0.000 (with encoder, without MDL inverter card), the parameter is not applicable. If the MDL is fitted,
sets the real conveyor speed within the range BL
-
BM..
All models
Remote Possible settings Standard setting Parameter
Belt max. sp.
BM
See below -
Global
Description Models
Maximum transit speed
This parameter appears only if the variable speed inverter module (MDL) is fitted (KT > 0.000) or an encoder is
connected (KE>0). In case an encoder is fitted instead of the MDL, the range is BL – 250 m/min.
BL
≤
BM
≤
(MI x KT)
The parameter is not applicable in case of fixed-speed or no conveyor belt.
Variable-speed conveyor belt: select the maximum operating speed.
If the inverter is fitted, BM
≤
MI x KT ; Alteration of parameter KT or MI results in automatic assignment of BM= MI x
KT
All models,
except THS/G
Ejection time menu
Remote Possible settings Standard setting Parameter
Alarm relay time
AT
0 – 20 s / A A
Global
Description Models
Alarm relay activation time
When set to A (automatic) the alarm relay is activated only for the time that the signal exceeds the alarm threshold.
If AT>0, the alarm relay is activated for the time that the signal exceeds the alarm threshold plus AT seconds.
If AT=0 the relay is not activated.
All models
Remote Possible settings Standard setting Parameter
Ej. relay time
ET
1 – 3000
hundredths of a second
-
Global
Description Models
Ejection relay activation time
If EM=S this parameter represents the ejection relay activation time after an alarm.
If EM=F: this parameter represents the minimum ejection relay activation time, because the relay is activated for a
length of time given by the sum of the alarm time (the transit time of the metal mass through the probe) and time ET.
All models
Remote Possible settings Standard setting Parameter
Confirm time
CT
0 – 6000
hundredths of a second
-
Global
Description Models
Confirm ejection time
With the Ejection Confirmation activated (CE=ON), after activation of the ejection relay the status of the “eject
confirmation” input is checked; if, after time CT, the input has not been activated (see parameter IE), the “fault
ejection” status is activated (fault relay, visible and audible indicators activated, message “Fault: ejection” displayed).
This may be caused by the failure to move a contaminated pack into a storage container. The “fault ejection” status is
activated if the input remains active for a few seconds – e.g. if a pack is jammed. The alarm is reset by pressing the
key.
All models
