THS – FI022GB2K8v3 --- V - MAINTENANCE
41
Conveyor Control System: Power-supply and motor connections
MDT card
N
E2199
PE
Fig. II-37a
MDT card connections for 230V power supply
N
E2199
PE
Fig. II-37b
MDT card connections for 400V power supply
Table II-E: MDT card connections for three-phase 230V power supply
Connector Pin Label
Input/
Output
Type Range /Max. value Function
MDT-J23
1
2
3
4
5
1
2
3
4
5
-
-
Input
Input
Input
Ground
Neutral
L3 Phase
L2 Phase
L1 Phase
-
-
230V -18% / +10% , 48-62Hz
230V -18% / +10%, 48-62Hz
230V -18% / +10%, 48-62Hz
safety ground PE
Not used
Power supply
Power supply
Power supply
MDT-J24
1
2
3
4
5
1
2
3
4
5
Output
Output
Output
-
-
W Phase
V Phase
U Phase
-
Ground
Input voltage and frequency, 5A (8A breakaway current)
Input voltage and frequency, 5A (8A breakaway current)
Input voltage and frequency, 5A (8A breakaway current)
-
-
Motor power supply
Motor power supply
Motor power supply
Not connected
safety ground
MDT-J25
1
2
3
4
5
1
2
3
4
5
Input
Input
-
Input
Input
NA Cont.
NA Cont.
Shield
NC Cont.
NC Cont.
0 - 26Vcc
0 - 26Vcc
0 - 26Vcc
0 - 26Vcc
Normally open motor thermal
protection contact
Shield
Normally closed motor thermal
protection contact
MDT-J26
1
5
1
5
Output
Output
L3 Phase
L2 Phase
230V -18% / +10% , 48-62Hz
230V -18% / +10% , 48-62Hz
ALM card power supply
ALM card power supply
Table II-F: MDT card connections for three-phase +neutral 400V power supply
Connector Pin Label
Input/
Output
Type Range /Max. value Function
MDT-J23
1
2
3
4
5
1
2
3
4
5
-
-
Input
Input
Input
Ground
Neutral
L3 Phase
L2 Phase
L1 Phase
-
-
400V -18% / +10% , 48-62Hz
400V -18% / +10%, 48-62Hz
400V -18% / +10%, 48-62Hz
safety ground PE
Neutral
Power supply
Power supply
Power supply
MDT-J24
1
2
3
4
5
1
2
3
4
5
Output
Output
Output
-
-
W Phase
V Phase
U Phase
-
Ground
Input voltage and frequency, 5A (8A breakaway current)
Input voltage and frequency, 5A (8A breakaway current)
Input voltage and frequency, 5A (8A breakaway current)
-
-
Motor power supply
Motor power supply
Motor power supply
Not connected
safety ground
MDT-J25
1
2
3
4
5
1
2
3
4
5
Input
Input
-
Input
Input
NA Cont.
NA Cont.
Shield
NC Cont.
NC Cont.
0 - 26Vcc
0 - 26Vcc
0 - 26Vcc
0 - 26Vcc
Normally open motor thermal
protection contact
Shield
Normally closed motor thermal
protection contact
MDT-J26
1
2
1
2
Output
Output
L3 Phase
Neutral
230V -18% / +10% , 48-62Hz
230V -18% / +10% , 48-62Hz
ALM card power supply
ALM card power supply
MDT - 400Vac: ALM card power supply: pay attention to the connections at connector J26, illustrated in the
figure: power supply to card ALM (230V) uses one input phase and the neutral connection. WARNING! incorrect
connection may cause permanent damage to the ALM card.
