Ceia THS - Description; General Information

THS – FI022GB2K8v3 --- I -DESCRIPTION
1
DESCRIPTION
General Information
The THS is an extremely compact metal detector with very high sensitivity, controlled by a microprocessor and
designed for industrial use. The device is made up of:
the Metal Detector probe, complete with electronic control unit.
a power-supply and control unit, for connecting the device to mains power and to the external
supports (photocell, ejector, etc.)
1 probe- Metal Detector
2 power supply unit with conveyor belt control
(Control Power Box)
3 connecting cable
4 tunnel
5 control panel
Fig. I-1a - THS system (probe-electronics unit + Control
Power Box power supply unit) installed on a
CEIA conveyor belt.
1 probe- Metal Detector
2 power supply unit with conveyor belt control
(Conveyor Control System)
3 conveyor belt load-bearing structure
4 conveyor belt control panel
5 idler
6 motor roller
Fig. I-1b - THS system (probe- Metal Detector +
Conveyor Control System power supply unit)
installed on a CEIA THS-FB conveyor belt.
