THS – FI022GB2K8v3 --- V - MAINTENANCE
31
Applications at high speed (belt speeds greater than 60 m/min)
In this case, the response times of the photocell, metal detector and ejector can not be ignored. We would generally
advise users to check operation of the ejector experimentally, changing its position and adjusting parameter ED.
Programming used in a few common types of installation
Belt block without ejector
ed
Photocell at entrance, with ejector
E
F
ed
pd
parameter
code
description value parameter
code
description value
EM
BS
EJ
ED
ejection mode
speed
ejection
ejection distance
B, BS (belt block)
belt speed (m/min)
ON
ed (mm) pack stop position
EM
BS
PL
IP
ET
LO
EJ
ED
PD
PH
ejection mode
speed
pack length
photocell input
ejection time
input logic
ejection
ejection distance
dist. ph.- metal det.
photocell position
S (synchronised)
belt speed (m/min)
length of pack (cm, only for THS/M)
NO: normally open /NC: norm. closed
ejection time (hundredths of a second)
N: negative / P: positive
ON
ed (mm)
pd (cm)
IN
Photocell at exit, with ejector
pd
ed
F
E
Retractable belt
ed
parameter
code
description value parameter
code
description value
EM
BS
IP
ET
LO
EJ
ED
PD
PH
ejection mode
speed
photocell input
ejection time
input logic
ejection
ejection distance
dist. ph.- metal det.
photocell position
S (synchronised)
belt speed (m/min)
NO: normally open NC: norm. closed
ejection time (hundredths of a sec)
N: negative / P: positive
ON
ed (mm)
pd (cm)
OUT
EM
BS
ET
EJ
ED
ejection mode
speed
ejection time
ejection
ejection distance
F (flap)
belt speed (m/min)
ejection time (cs)
ON
ed (mm)
Fig.II-28 F: photocell E: ejector
