Ceia THS - Ths;G; Ths-Fb

THS – FI022GB2K8v3 --- VI - APPENDICES
95
THS/G
Validity: revision 3.300, 30/06/2003
Spare parts
Description Quantity Code
Control panel 1 18736
SPM module 1 21853
Cable connecting the probe to the power supply unit: length 3 metres 1 18940
Cable connecting the probe to the power supply unit: custom length (max. 40m) 1 19992
Power supply unit 1 21141
Power supply card 00208ALM 1 18939
Remote control card 00208RCU 1 18945
Options
Description Quantity Code
RS 485 interface 1 17828
400/230Vca Transformer Box 1 23182
Protection against high-pressure water cleaning 1 24775
Ethernet Module 1 29756
Key for flange mounting
1 23376
Accessories
Description Quantity Code
MDScope 1 19795
MDCAD 1 27185
THS REPORT 1 27184
RS232/RS485 converter 1 21540
Infeed conveyor ø
in
330mm - ø
out
126.5mm PM2034A 1 23435
Infeed conveyor, part 1 code 2-37, ø
in
330mm, ø
out
161mm 1 23353
Infeed conveyor, part 2 code 2-39, ø
in
172mm, ø
out
126.5mm 1 23223
Infeed conveyor ø
in
330mm - ø
out
102.5mm PM2035A 1 23434
Infeed conveyor, part 1 code 2-37, ø
in
330mm, ø
out
165mm 1 23353
Infeed conveyor, part 2 code 2-41, ø
in
161mm, ø
out
152mm 1 23221
Infeed conveyor, part 3 code 2-42, ø
in
147mm, ø
out
142mm 1 23356
Infeed conveyor, part 4 code 2-43, ø
in
142mm, ø
out
126mm 1 23355
Infeed conveyor, part 5 code 2-44, ø
in
134mm, ø
out
102.5mm 1 23354
Infeed conveyor ø
in
330mm - ø
out
82mm PM2036A 1 23433
Infeed conveyor, part 1 code 2-37, ø
in
330mm, ø
out
165mm 1 23353
Infeed conveyor, part 2 code 2-38, ø
in
161mm, ø
out
110mm 1 23222
Infeed conveyor, part 3 code 2-40, ø
in
111mm, ø
out
82mm 1 23357
THS-FB
Validity: revision 1.06, 10/05/2002
Spare parts
Description Quantity Code
Belt 1 2 Tab. A
Trespa support plate - long part 1 7 Tab. A
Trespa support plate - short part 1 8 Tab. A
Plate spacer/support 1 9 Tab. A
Plate and reflektor spacer/support 1 10 Tab. A
Power supply unit and blinking light support kit 1 11 Tab. A
Reflektor support 1 12 Tab. A
Drum motor with wiring 1 15 Tab. A
250mm Drum motor 1 24922
300mm Drum motor 1 24715
350mm Drum motor 1 24923
400mm Drum motor 1 24716
450mm Drum motor 1 24918
500mm Drum motor 1 24717
600mm Drum motor 1 24718
Photocells 1 18486
Orange blinking light module 1 21280
Buzzer module 1 21281
Support for buzzer/blinking light 1 21282
Support for blinking light 1 20359
Supports for Free roller 1 21428
Bearing for Free roller and Bend roller 1 24605
Supports for Drum motor 1 21429
00208SCN connection card 1 21917
Casing for connectio card - drum motor side 1 21623
Casing for connectio card - supply box side 1 21622
Roller tilting support - right side 1 20803
Roller tilting support - left side 1 20804
Drum motor support - right side 1 20805
Drum motor support - left side 1 20806
General purpose support 1 21243
6mm diameter blue air rubber pipe 1 20958
8mm diameter blue air rubber pipe 1 21601
PG9 plug 1 22315
