Ceia THS - Technical Characteristics

THS – FI022GB2K8v3 --- I -DESCRIPTION
13
Technical Characteristics
Control Power Box
Standard power supply
unit
In watertight casing (grade of protection: IP65)
Dimensions: 250x150x300mm (wxdxh)
Power supply voltage: 115/230 V~ (+10 / -22%), single phase - 48/62 Hz
Maximum power absorbed: 60 VA (THS/MN: 200VA)
Conveyor Control
System
Power supply unit with
inverter card
In watertight casing (grade of protection: IP65)
Dimensions: 250x180x300mm (wxdxh)
Models available
Version
Application Input Voltage Maximum
power
absorbed
Output voltage
(motor power supply)
*
Maximum
power of
motor
Conveyor Control System/MDT
with MDT module for 230V power
supply
Fixed speed 230V -18% / +10%,
three-phase without
neutral, 48-62Hz
1250VA 230V -18% / +10%,
three-phase 48-62Hz
750W
Conveyor Control System/MDT
with MDT module for 400V power
supply
Fixed speed 400V -18% / +10%,
three-phase with
neutral, 48-62Hz
2500VA 400V -18% / +10%,
three-phase 48-62Hz
1500W
Conveyor Control System/MDL
with MDL module
Variable speed
230V ± 10% single-
phase 48-62Hz
1000VA 230V three-phase
20-60Hz
750W
* three-phase asynchronous motor , delta connection
Probe-electronics unit
Tunnel-shaped metal structure containing the sensitive antenna and the control panel
Dimensions: see preceding pages.
Special features
• Ultra-high sensitivity
• High immunity to environmental interference
• LCD display (4 lines of 20 characters each) to show data
• Remote or direct programming of the operating parameters (type of product,
immunity level, speed of transit, processing of signal, control over external
actuators, etc.) by means of keyboard
• Audio and visual detection indicators.
• Display of the signal level by means of bar-graph.
• Statistical analysis of the number of inspected and contaminated products
• ISO 9001 product quality control
• THS/A model: model with tunnel that can be opened
• Model THS/SL (Slim Line): extremely compact probe
• Model THS/3F: detector for magnetic and non-magnetic metals, for use with
different types of product thanks to selection of the operating frequency
• Model THS/PH: model especially designed for the pharmaceutical industry
• Model THS/M: detection of ferromagnetic metals when considerable quantities of
aluminium or other non-magnetic metals are present
• Model THS/G: probe with circular opening for checking material transported in
tubing.
Password
6 levels: operator / supervisor /engineer/ quality control operator / head of quality
control / remote programming
Stored sets of
parameters
250 sets of parameter settings may be stored, corresponding to 250 possible different
products
