THS – FI022GB2K8v3 --- I - DESCRIPTION
14
Control inputs
Connector for link-up to
• photocell
• manual reset button
• downstream belt authorisation
• ejection confirmation
• set-aside contained full sensor
• encoder to detect the belt speed
• emergency button
• barcode reader (on demand)
• compressed air pressure sensor (for ejection)
Serial interface RS232
Serial interface RS485 (on request)
Outputs
5 programmable relays (250Vac - 3A) to activate the external support units
•alarm relay
•malfunction relay
•ejector relay
•upstream belt authorisation relay
•auxiliary relay
Ejection
The system can use the following types of ejector:
•compressed air jet
•piston
•retractable belt
Power: compressed air (200-1000 kPa), pressure: 600 litres/min (airblow ejector); 50
litres/min (piston ejector); 100 litres/min (retractable belt ejector).
Alarm signalling
Visual
: by means of indicator light on central electronics unit
Audio
: by means of buzzer on central electronics unit
By means of output relays
Environmental
conditions
Working temperature: 0-50°C
Humidity: 5-90%, without condensation
System including
conveyor belt
Belt available in PVC approved for food handling on request.,
Dimensions, weight and accessories: see the configuration sheet at the end of the
manual.
