THS – FI022GB2K8v3 --- V - MAINTENANCE
54
Display of the status of the Metal Detector
If the (increase) key is pressed when the display shows normal operation, a list of information relating to the Metal
Detector’s status is shown:
THS/M
THS/MN V3.xxx
Product productname
|
Sensitivity 265
Cur Alar. 10
Cur. Obj. 156
Time 12:34
Date 24/10/97
Next test 15:00
Fig. III-11a
Other THS models:
THS V3.xxx
Product productname
|
Sensitivity 265
TX program 0
Cur Alar. 10
Cur. Obj. * 156
Time 12:34
Date 24/10/97
Next test 15:00
Fig. III-11b
* not present on THS/G models
Use of the conveyor belt
Starting/stopping the conveyor belt
With the correct power supply and with the motor stopped, check that the LED indicators are on or off as
shown in the following table:
Indicator
Status
mains voltage
on
motor on
off
motor off
on
motor malfunction
!
M
off
metal detector alarm
!
off
• Press the start/stop button
to switch on the motor: check that it starts up, and that the “motor
on” indicator
comes on and the “motor off” indicator goes off.
• To stop the motor press the start/stop button
again: check that it stops, and that the “motor
on” indicator
goes off and the “motor off” indicator comes on.
• Fixed-speed Conveyor Control System: check the manual movement of the motor using the
and keys
(if parameter MM=ON).
Adjustment of the belt speed
The motor speed control keys have different functions according to the value of parameter MM (see Programming
section).
The speed of the conveyor belt can be adjusted by:
• programming the BS parameter on the metal detector
• simply pushing the keys located on the Conveyor Control System, if parameter MM=OFF.
N.B.: during programming of the metal detector, the Conveyor Control System keypad is disabled. Vice-versa, while the
Conveyor Control System keys are being used, metal detector programming is disabled.
