THS – FI022GB2K8v3 --- V - MAINTENANCE
86
Storage
Store the system in its original packaging, or in a way that protects it adequately from atmospheric agents or other
possible causes of damage (moving objects, weights, solvents etc.).
Storage temperature (Regulation EN 60204): -25°C - +55°C long-term, +70°C for 24 hours maximum.
Transport and movement of the conveyor belt
Disconnect the system from the various power sources before carrying out any movement.
Use lift trucks or sling the load-bearing structure, and ensure that the load is balanced during movement. Avoid
deforming the structure or its component parts.
Never attach lifting gear to the Metal Detector probe or the actuators.
Keep the packaging materials for possible future transport.
Fig. V-2
Adjustment of conveyor belt tension
This is carried out on the roller on the side opposite the motor roller. To adjust the belt tension, loosen screws A on both
sides by the same number of turns, so that the slack in the belt at the entrance to the probe appears as in the figure
(about 0.02 x length of the belt, s=0.02 D).
D
s
Fig. V-3a Fig. V-3b
A
