M-Series Operator’s Manual 4/9/15
10-49
F5 – Tangent: Line Arc Arc
Given the center points (C1 and C2) and radii (R1 and R2) of two arcs, find the lines (defined by T1 – T2) tangent to
both arcs.
You must enter the X and Y coordinates for the first circle's center point, the radius of the first circle, the X and Y
coordinates for the second circle's center point, and the second circle's radius.
F6 – Tangent: Arc Arc Arc
Given the center points (C1 and C2) and radii (R1 and R2) of two arcs and the radius of a third arc, find the center
point of the third arc and the tangent points (T1 and T2).
