M-Series Operator’s Manual 4/9/15
10-70
N0004 Tool change
Tool Number :
2
Description :
0.250 Dia End Mill
Position: X
:
0.0000
Y
:
0.0000
Tool H Offset :
2
(Tool Height) :
(Your tool)
Tool D Offset :
2
Tool Diameter :
0.2500
Spindle Speed :
1000
Spindle Direction :
CW (M3)
Coolant Type :
Flood (M8)
Actual Tool Change
:
Yes
F10 - Accept Keep selected values.
F5 - Cycles Access the list of available canned cycles.
F6 - Circ. Pocket Start with 1.2000 inch diameter Pocket.
N0005 Circular pocket
Center: X :
0.0000
Y :
0.0000
Surface Height
:
0.0000
Diameter :
1.2000
Cleanout :
Yes
Depth: Total
:
0.5100
INC
Per Pass
:
0.2500
Plunge Rate
:
2.0000
[M]
Plunge Type
:
Ramped
Plunge Angle
:
0.00
°
Rough Cuts :
Conventional
Stepover
:
0.2000
Feedrate
:
2.0000
[M]
Finish Pass :
Climb
Amount
:
0.1000
Feedrate
:
2.0000
[M]
F10 - Accept Keep selected values.
F5 - Cycles Access the list of available canned cycles.
F6 - Circ. Pocket Repeat above pocket cycle. The center X value 4.0000 and the
diameter is 0.7500 inches.
