M-Series Operator’s Manual 4/9/15
10-82
↑
↑↑
↑↓
↓↓
↓(UP/DOWN) Highlight the needed tangent point X. Tangent point T1 is the
one you want this time.
ARROWS If necessary, move the cursor to the arc operation and select the
End X field.
F8 - Copy >>> Transfer the tangent point T1 value for X into the end point X
coordinate. The active fields on both sides of the screen advance
automatically.
F8 - Copy >>> Transfer the tangent point T1 value for Y into the end point Y
coordinate.
F6 - Hide Math Hide Math Help.
ARROWS Move down to the radius field and enter the radius of the arc
labeled ARC 4 in Figure 3. (This radius is 3.1500 inches). Be
sure to set the direction to CCW.
Arc type :
EP&R
Mid: X
:
Y
:
Z
:
End: X
:
3.7746
Y
:
0.5829
Z
:
-0.0500
Center: X
:
Y
:
Z
:
Angle :
Radius :
3.1500
Plane :
XY
Direction :
CCW
Feedrate :
10.0000
Angle <= 180°
:
Yes
F10 - Accept Keep selected values.
F3 - Arc Mill the arc labeled as ARC 5 in Figure 3 back to point P1.
