M-Series Operator’s Manual 4/9/15
10-83
N0017 Arc mill
Operation type
:
EP&R
Mid: X
:
Y
:
Z
:
End: X
:
4.6250
Y
:
0.0000
Z
:
-0.0500
Center: X
:
Y
:
Z
:
Angle :
Radius :
0.6250
Plane :
XY
Direction :
CW
Feedrate :
10.0000
Angle <= 180°
:
Yes
F10 - Accept Keep selected values.
F3 - Arc Move tool away from the edge of the part after the last arc.
N0018 Arc mill
Arc type :
EP&R
Mid: X
:
Y
:
Z
:
End: X
:
5.0000
Y
:
-0.5000
Z
:
-0.0500
Center: X
:
Y
:
Z
:
Angle :
Radius :
0.5000
Plane :
XY
Direction :
CCW
Feedrate :
10.0000
Angle <=180°
:
Yes
F10 - Accept Keep selected values.
F7 - Cutter Comp Hit the space bar until cutter compensation is turned 'Off'. It is no
longer needed.
N0019 Comp off
F10 - Accept Keep selected values.
