M-Series Operator’s Manual 4/9/15
10-84
F1 - Rapid Move the tool away from the part. This is called a lead-out move.
When cutter compensation is turned off, the compensation is
removed during the next move. This must be done to allow the
CNC software to correct its position.
N0020 Rapid traverse
End: X
:
5.0000
Y
:
-0.5000
Z
:
0.1000
Angle :
0.0000°
Length
:
0.0000
F10 - Accept Keep selected values.
F9 - Subpgm Access the Subprogram screen.
F1 - Depth Repeat We programmed the outer contour of the part so that our tool
would only penetrate a small portion of the material per pass. We
now want to repeat the outer contour operations until the tool has
cut the entire way through the material (the assumed material
thickness is 0.5 inches). The outer contour begins with the
Plunge in operation N0011 and ends with the Linear Mill in
operation N0017.
N0021 Repeat to Depth
Start Block :
0011
End Block :
0020
Total Depth :
0.5100
INC
Depth Increment :
0.0500
INC
Clearance Height
:
0.2500
Plunge Rate :
5.0000
F10 - Accept Keep selected values.
F1 - Rapid Move the tool away from the part. This is called a lead-out move.
When cutter compensation is turned off, the compensation is
removed during the next move. This must be done to allow the
CNC software to correct its position.
N0022 Rapid traverse
End: X
:
0.0000
Y
:
0.0000
Z
:
3.0000
Angle :
174.2894°
Length
:
5.0249
F10 - Accept Keep selected values.
