M-Series Operator’s Manual 4/9/15
Parameter Definition Default setting
19 MPG modes 0
20 Ambient Temperature 72°F / 22°C
21-24 Motor Heating Coefficients for axes 1,2,3,4 Refer to text
25-28 Motor Cooling Coefficients for axes 1,2,3,4 Refer to text
29 Warning Temperature 150°F / 65.5°C
30 Limit Temperature 180°F / 82°C
31 Legacy SPIN232 Com Port 0
33 Spindle Motor Gear Ratio 1
34 Spindle Encoder Counts/Rev 8,000
35 Spindle Encoder Axis Number 0
36 Rigid Tapping Enable/Disable 0
37 Spindle Deceleration Time 10
38 Multi-Axis Max Feedrate 0
39 Feedrate Override Knob Limit 120
40 Basic Jog Increment 0.0001” / .001 mm
41 Rotary Axis Jog Increment .01°
42 Password for Configuration Menus 0
43 Automatic tool measurement options 0
44 TT1 PLC input # 0
48 Grid Digitize Patch Playback Z rapid clearance amount .1
49-51 Small Arc Feedrate Limiting 0
56 Feedrate Override Display Properties 0
57 Use Generic Load Meter Data from PLC 0
61 High Power Stall Timeout 0.5
62 High Power Stall PID Limit 115
63 High Power Idle PID Multiplier 1.5
64 4
th
/5
th
Axis Pairing 0
65-67 Spindle Gear Ratios 1.0
68 Minimum Rigid Tapping Spindle Speed 0
69 Duration For Minimum Spindle Speed 1.0
70 Offset Library Inc/Decrement Amount .001" / .02 mm
71 Part Setup Detector Height 0
72 Data Recording M-Function Options 0
73 Peck Drill Retract Amount 0.05
74 M-Function executed at bottom of tapping cycle 4
75 Axis Summing Control 0
76 Manual Input Unrestricted Distance 0
77 Manual Input Movement Tolerance 0
78 Spindle Speed Display and Operations 0
80 Voltage Brake Applied Message Frequency 0
81 Air Drill M-Function (executed instead of Z movement in drilling)
-1
82 Spindle Drift Adjustment 0
83 Deep Hole Clearance Amount 0.05
84 M-Function executed at return to initial point of tapping cycle 3
85 “Door Open” Interlock PLC bit 0
86 Rapid/Linear vector rate limit 0
87-90 Autotune Ka Performance parameters for axes 1,2,3,4 0
