M-Series Operator’s Manual 4/9/15
Parameter Definition Default setting
91-94 Axis Properties for axes 1,2,3,4 0
95-98 Autotune / Auto Delay Move Distance for axes 1,2,3,4 2” / 50.8 mm
99 Cutter Compensation Look-ahead 6
100 Intercon comment generation 0
101 Intercon clearance amount 0.1
102 Intercon spindle coolant delay 3.0
103 Intercon corner federate override 50.0
104 Intercon modal line parameters 0
105 Intercon modal arc parameters 0
106 Intercon modal drilling cycle parameters 0
115 Intercon Help 0
116 A-Axis Y Coordinate 0
117 A-Axis Z Coordinate 0
118 B-Axis X Coordinate 0
119 B-Axis Z Coordinate 0
120 Probe stuck clearance amount 0.10” / 2.54 mm
121 Grid digitize prediction minimum Z pullback 0.002” / .0508 mm
122 Grid digitizing deadband move distance 0.0002” / .00508 mm
123 Radial digitizing clearance move 0
130 Z axis on/off selection 0
131 4
th
axis on/off selection 0
132-135 Motor Heating Coefficients for axes 5,6,7,8 Refer to text
137 Load Meter Filter Size 0
138 DRO Encoder Deadband 0
139 Special Dwell between Moves 0
140 Message log priority level 1
141 Maximum message log lines 100
142 Message log trim amount 100
143 DRO properties (load meters, 4/5 digits, DTG) 0
144 Comparison rounding 0
145 Advanced macro properties (fast branching) 0
146 Feed hold threshold for feed rate override 0
147 Number of Messages in Operator Message Window 10
148 Miscellaneous Jogging Options 0
149 Spindle Speed Threshold 1.0
150 Backplot Graphics display options 0
151 Repeatability tolerance for probing 0
155 DSP Probe Installed 0
156-159 Autotune / Auto Delay Move Distance for axes 5,6,7,8 2” / 50.8 mm
160 Enhanced ATC 0
161 ATC Maximum Tool Bins 0
162 Intercon M6 Initial M-Code 0
164 ATC Feature Bit 0
165 Acceleration/Deceleration Options 0
166-169 Axis Properties for axes 5,6,7,8 0
170-177 PLC parameters 0
178 PLC I/O configuration (PLC program specific) 0
