M-Series Operator’s Manual 4/9/15
2. P230 Curve Feedrate multiplier Arcs and Corners
Low values produce lower feedrates in curves.
Fig. 4a: P230 determines speed around curves and arcs
Tighter arcs produce lower feedrates
3. P231 Acceleration Multiplier
Fig. 4b: Lower values produce lower accelerations.
4. Min_Angle (P227) defines the minimum angle to apply Smoothing to. All angles below the minimum angle
will be sharp. For example if Min Angle is set to 95deg then all angles less than 95 right angle (including 90deg)
corners will be sharp (not smoothed).
Velocity
Time
P231
