MAIN (2) - Diagnostics
The logbooks must be copied and deleted from the memory card at regular
intervals, as the storage space on the memory card is limited. Using the
QDM software there are two options: Via the backup functions or the man-
agement functions.
The system logbooks are allocated to a certain welding power source but
this allocation cannot be seen in the logbooks. It is important that this allo-
cation is not lost when the logbooks are archived or are copied again later
into the data management of the application.
The date for every logbook is indicated in the menu "Diagnostics" -->
"System logbook" --> "Logbook selection". The number of entries indicates
the number of logbooks.
SYSTEM - LOGBUCH
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Datum : TT.MM.JJJJ
Uhrzeit : HH:MM:SS
Name :
Doku-Nr. : 3
Details :
Diagnose Systemlogbuch
Logbuch
Auswahl
3/9999
X 1000
Handrad
Figure 62. Diagnostics System logbook menu
INFO!
Diagnose Systemlogbuch (2)
Systemlogbuch - Auswahl
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
XX Einträge
Logbuch
löschen
Figure 63. Diagnostics System logbook selection menu
