Function Description
Interval
Using this function, you set the speed of the parameter
change released by the torch trigger. The adjustment is
between 1 … 10. The correction value is 100 ms each.
Step width
Using this function, you set the size of the parameter
change released by the torch trigger. The adjustment
is between 1 … 20. The correction value is 0.1 m/min
each for the "Power" and 1 % each for the "Fine" and
"Dynamic" parameters.
10.1.3 Control coolant pump and fan
If an external cooling is connected, make sure that it is recognised by the
welding power source. The functions described here are then transferred
to the external cooling.
Function Description
Automatic
Depending on the thermal load, the calculator of the
welding power source controls the running time of the
cooling pump and the fan.
On
As soon as the main switch of the welding power source
is switched on, the cooling pump and the fan start their
continuous operation.
The pump and the fan only turn off if the welding
power source is switched off.
Off The pump and the flow monitoring are switched off.
The menu is quit by pressing rotary knob 3!
10.2 Config - General (2)
ATTENTION!
Display Konfig Allgemein (2) ab V10
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Konfig – Allgemein (2)
Drahtvorschub - Anzeige
Drahtvorschub in m/min
Klemmen-/Prozessspannung
Display zeigt
Prozessspannung
Grenzwerte Gas-Ja Signal
Min [l] 8.0
Max [l] 30.0
Figure 31. Config General (2) menu
To Next Page
