11.8 Diagnostics pulsed arc synchronisation
The synchronisation mode of the welding power source is shown in this
menu.
11.9 Diagnostics System logbook
If a memory card is inserted in the control board of the welding power
source, the welding power source saves all system messages on this
memory card. System messages can be error entries (water monitoring,
temperature error etc.) or documentation entries (user registration, save/
delete job etc.).
The menu "Diagnostics" --> "System logbook" of the welding power source
shows all existing entries in chronological order.
An entry contains the following information:
Time stamp
The time stamp of the logbook entry. At this time the
welding power source saved the entry in the logbook.
User The user who was active when the entry was saved.
Error no. /
Docu no.
For an error entry, the error number and for a documen-
tation entry, the documentation number that identifies
the entry.
Error text /
Docu text
The text belonging to the respective error number /
documentation number.
Details An additional information according to entry.
Diagnose Impulssynchronisation
Taktgeber
Diagnose - Impulssynchronisation
Puls 4 -Takt
V
A
1.2 mm Fe
82% Argon 18% Co
0.0
Synchronisation-Modus
Taktgeber
Frequenz 200 Hz
Phasenverschiebung 50 %
Taktgeber aktiv
Synchronisation aktiv
Figure 61. Diagnostics Pulsed arc synchronisation menu
