8. Technical data
Type: QINEO CHAMP Pro
CHAMP 451 Pro CHAMP 601 Pro
Ambient conditions
Operating temperature °C -10°C…+40°C
Storage temperature °C -25°C…+55°C
Humidity
50% at 40°C
90% at 20°C
Ambient air
Free of unusual dust
Free of aggressive media
Welding range
40A/16V-450A/36.5V 40A/16V-600A/44V
EMC
Class
A A
Open circuit voltage
(V)
75 84
Data 60% duty cycle
I2 60% secondary (A)
450 600
U2 60% secondary (V)
36.5 44
I1 60% primary (A)
33.1 53.9
S1 60% primary (kVA)
22.4 36.3
Data 100% duty cycle
I2 100% secondary (A)
350 465
U2 100% secondary (V)
31.5 37.5
I1 100% primary (A)
22.4 34.5
S1 100% primary (kVA)
15.2 23.4
Mains voltage 1
(V)
3/PE 400V 3/PE 400V
Fuse 1 (slow or "D")
(A)
32 50
Further data
Connection cable
4x6 4x10
Type of protection
IP23 IP23
Type of cooling
F F
Insulation class
F F
Noise emission value in idle running dB(A) =< 70
Dimensions (L x W x H) (mm) 1226 x 630 x 942
Weight approx.: (kg) 204 244
You find the technical data of the wire drive units in block 5 "QWD".
