103
13. MAIN (2) - Data backup
In the "Data backup" menu, so-called jobs can be written from the welding
power source to the SD memory card or from the SD memory card to the
job memory of the welding power source.
Insert the SD memory card into the card slot below rotary knob 3. Press the
"Data backup" function.
13.1 Copy job to SD memory card
All jobs in the job memory of the welding power source are displayed.
Save a single job
Use rotary knob 3 to select the job to be saved and confirm the selection
by pressing rotary knob 3 (Enter function). The job will be saved on the SD
memory card.
Save several jobs
Use the function "from Job" to select the beginning of the block, e. g. Job 1.
The display shows "Block Start" and the selected job number in yellow. Now
select by means of rotary knob 3 the end of the block, e. g. job 7 and press
the function "to Job".
Press rotary knob 3 to save the marked block on the SD memory card.
Job > Card
D A T E N S I C H E R U N G
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Card > Job
Syn > Card
Card > Syn
Cfg > Card
Card > Cfg
Job > Card
D A T E N S I C H E R U N G
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Card > Job
Syn > Card
Card > Syn
Cfg > Card
Card > Cfg
Figure 65. Data backup
