11. MAIN (2) - Diagnostics
The diagnostics menu provides the following submenus:
• Status of the cooling system.
• Query of the power class and the software versions.
• Input / output occupancy of different functions.
• Status on the QWD (Wire Drive).
• PC adaptation with information about the MAC address, IP address and
Subnet mask of the welding power source.
• Display of Tandem state and Tandem configuration.
• Display of the configuration of pulsed arc synchronisation.
• Display of the entries in the system logbook.
• Display of the robot communication state.
Figure 51. Diagnostics menu
Diagnose > V.10
Kühlung
D I A G N O S E
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Software
Versionen
I / 0
QWD
PC
Anpassung
Tandem
Impuls-
sync.

Diagnose (2) > V.12
D I A G N O S E (2)
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0

System-
Logbuch
Roboter
Figure 52. Premium Diagnostics_General_(2)
