CHAMP Pro

2. Connection overview optional interfaces

Name Connection Notes

Ethernet (X77)

System plug for:

Periphery / CAN (X7)

Seam tracking (X33)

Gas nozzle sensor (X34)

OMI (X70)

Tandem / Pulse

synchronisation (X32)

Qineo Pulse Pro

Qineo Champ Pro

Standby for external

cooling (X40)

DeviceNet (X74)

ProfiBus (X72)

ProfiNet (X73)

To guarantee compatibility with old devices:

Seam tracking (X33) On request.

Gas nozzle sensor (X34) On request.
