31
1
Connection wire drive
2
Ethernet
3
Welding current bushing
4
Connection designations, see
chapter 2.
5
ext. Cooling, optional
6
Tandem, optional
7
Coolant supply and return
8
Mains connection
9
Seam tracking
10
Maintenance access Pump
11
Coolant drain cock
12
Inspection window coolant
13
Coolant filler neck
1
2
3
4
5
6
7
8910
11
12
13
Figure 7. Rear view QINEO Champ Pro
