Cloos QINEO - Config - General (3); Config - General - Basic Settings

74
MAIN (2) - Config (Configuration)
In this menu item you can:
• Select the dimension display for the wire speed.
• Select whether the display shows the process voltage (terminal voltage
minus values of the external welding current circuit = calculated volt-
age at the workpiece) or the terminal voltage (voltage at the welding
power source).
• Determine the minimum and maximum limit values for the "Gas-Yes-
Signal" in litres.
10.3 Config - General (3)
In this menu item you determine the minimum and maximum value that
a welding torch equipped with a potentiometer can achieve in the TIG
welding process.
10.3.1 Config - General - Basic settings
Display Konfig Allgemein (3) ab V10
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Konfig – Allgemein (3)
Potistellbereich - WIG
Min [A] 0
Max [A] 0
Figure 32. Config General (3) menu
Display Konfig, Grundeinstellung ab V.12
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Konfig - Grundeinstellungen
Externe Ansteuerung
Anzahl Leitspannungen 3
Ext. Verfahrensanwahl Aus
Qirox Parameter Ein
Start-/Endprogramm im 2 Takt
Start-/Endeprogramm Aus
Feinabgleich-Variante
Feinabgleich über Kennlinie
Polung +/- Anschluss
+/- Anschluss Standard
Tandem
Auf
Werksein-
stellungen
zurück
Figure 33. Premium Config_Basic settings
