Cloos QINEO - Config - General - QWD

77
Sense technology On/Off
Mode: On or Off
Sense technology Differential voltage
Difference: 0.0 V…40.0 V
If the adjusted voltage is exceeded, the error message "Err. 25 Sense voltage
exceeded!" appears on the display.
10.3.1.3 Config - General - QWD
In this menu you configure which PushPull drive is connected to which
wire drive (QWD1 ... QWD4).
• No drive
• Cloos Arcette
• Cloos Arcette 2
• Binzel PP+401D
• TBI PPP 7G/7W
• Dinse DIX MPZ 304
• Not defined
Blocked drives will be displayed in red in the selection. These drives may be
activated optionally.
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Konfig - Grundeinstellungen
Sensetechnik Ein/Aus
Sensetechnik Differenzspannung
Differenz 10.0V
Modus Ein
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Konfig - Grundeinstellungen
Sensetechnik Ein/Aus
Sensetechnik Differenzspannung
Differenz 10.0V
Modus Ein
Figure 34. Config - Sense technology
