Cloos QINEO - Submenus

116
SD module
• Display
Change to different views by activating the function.
• Apply/Accept set value (during welding)
Activate the function to take over the currently measured actual vales as
set values to the activated monitoring channels.
• Reset / SD special function
Use this function to reset all error messages triggered during monitoring.
The function is not possible during welding!
If you press the menu key for longer than 2 seconds, the menu “SD special
function” will open.
In this menu you can:
• Save an SD configuration as “Default values“,
• Load “Default values“ of an SD configuration,
• Enter a component name,
• Reset the seam counter to 0
• Or change the value of the seam counter via the middle rotary
knob manually.
You can enter a 20 digit name for a component by means of the “Name”
function. The input is finished by pressing the “Enter“ function. The seam
counter can be manually reset to any value or to 0 by the “Reset” function,
see Figure 72.
3.2 Submenus
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
SD - Sonderfunktion
Bauteilname
Grundrahmen
Zähler
Name
Reset
Nahtzähler 0
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
SD - Sonderfunktion
Bauteilname
Grundrahmen
Zähler
Name
Reset
Nahtzähler 0
Figure 72. SD special function
