110
RC Plus (Remote Control)
For more information please refer to the separate operating manual.
1. RC Plus (Remote Control)
Figure 68. RC Plus
1
2
7
8
5
3
6
4
1 Quick save memory keys 1…4
2
Multi-functional key (hold value
display, selection actual value
display)
3 Selection key Processes
4 Selection key Operating modes
5 Job key (load job, quit job)
6 Display
7
Rotary knob left (capacity
adjustment)
8
Rotary knob right (fine
adjustment, dynamics)
