8.1.3 Consumption costs
This function shows the costs for the number of weld seams, wire, gas and
energy.
The cost analysis is started by means of the "Reset" function or is reset to 0.
9. MAIN - Display
This function enables switching between different display versions.
Version 1
In addition to the reference variable "Wire speed", the parameters "Sheet
thickness", "Aset" and "Vset" are displayed. In addition, the parameters
"ArcLength" and "ArcDynamic" are shown, see Figure 28.
The 3 parameters "Sheet thickness", "Aset" and "Vset" serve as orientation
to select suitable welding parameters. Due to the synergy characteristic
curves used, the parameters for the "Sheet thickness", "Aset" and "Vset" are
calculated on the basis of the wire speed value.
• The "Sheet thickness" display shows the possible sheet thickness to be
welded. It can only be used as a rough reference to determine the cor-
rect parameters. The sheet thickness refers to a fillet weld.
• The display "Aset" shows the welding current to be expected. Since this
is a calculated value, the real welding current may differ from the pre-
announcement!
• The display "Vset" shows the welding voltage to be expected. Since this
value has been calculated, the real welding voltage may differ from the
display!
Display Messwerte Verbrauchskosten (x.11)
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
B E T R I E B S D A T E N
Summenzähler
Betriebszeit 12:47 Std
Kosten ab Reset - 1 -
Schweissnähte 0
Verbrauch
Kosten
Datensatz
umschalt
1/2
Kosten
sätze
Schweisszeit 10:17 Std
Aktuelle Naht 12.4 Sek
Draht 0.00 Euro
Energie 0.00 Euro
Reset
Gas 0.00 Euro
Setup
Figure 27. Consumption costs
