Cloos QINEO - Page 183

183
• "Tandem mode" with only one wire in the Tandem torch ("Tandem-
Single Wire")
A wire drive unit of the master or the slave welding power source is used
depending on the application. The corresponding job selection is sufficient,
here 112, 113 or 212, 213. Select in the adjustments which wire is welded
with which synergy characteristic curve. Both gas valves are opened. The
seam tracking signal automatically comes from the welding power source
which is just welding.
• Master welding power source with additional single wire torch
If the master welding power source has a second wire drive unit with a
single wire torch, one job is enough to save the required adjustments, here
151 or 152.
• "Hot transfer" of the welding parameters from the "Tandem-Single
wire" to the "Tandem mode“ and vice versa
The welding power source which is added to or removed from the Tandem
mode has to be entered in the menu item "Synergy variant" as "Tandem
leading" and in the menu item "IPS mode" as "pulse generator".
In addition, the two welding parameter lists (start and end) and the program
selection (= job selection) must remain identical in the robot controller.
Job
number
Wire in
front
Wire in
the back
Operating
mode Tandem
"Seam track-
ing signal"
"Synergy variant" "Pulse synchronisation"
"Process"
"Master" "Slave" "Master" "Slave"
112 - S
"Slave single
wire T torch"
S Standard Standard async. async. S-Pulse
113 - S
"Slave single
wire T torch"
S Standard Standard async. async. Normal
212 - M
"Master single
wire T torch"
M Standard Standard async. async. S-Pulse
213 - M
"Master single
wire T torch"
M Standard Standard async. async. Normal
Job
number
Wire in
front
Wire in
the back
Operating
mode Tandem
"Seam track-
ing signal"
"Synergy variant" "Pulse synchronisation"
"Process"
"Master" "Slave" "Master" "Slave"
151 - - - M - - async. - Normal
152 - - - M - - async. - S-Pulse
Job
number
Wire in
front
Wire in
the back
Operating
mode Tandem
"Seam track-
ing signal"
"Synergy variant" "Pulse synchronisation"
"Process"
"Master" "Slave" "Master" "Slave"
101 M S "Tandem" M leading following
Pulse
generator
Pulse receiver
alternating
S-Pulse
111 - S
"Slave single
wire T torch"
S leading Standard
Pulse
generator
async. S-Pulse
201 S M "Tandem" S following leading
Pulse receiver
alternating
Pulse
generator
S-Pulse
211 - M
"Master
single wire T
torch"
M Standard leading async.
Pulse
generator
S-Pulse
