Web interface – Network Control Station Duetto
26 2.0/0518
Timeservers: In this field, enter the IP address to use internal or different external NTP servers
(separate more than one NTP server via space).
VLAN:
VLAN ID: In this field, enter the VLAN ID of a network. DUETTO will get access to this specific
network.
Port Authentication:
802.1X Mode: In this drop-down list, the 802.1X authentication mode can be selected.
The following modes are available:
802.1x mode - Off: The 802.1X function is disabled.
802.1x mode - EAP-TLS:
The 802.1X function is executed with the protocol
“Extensible Authentication Protocol
Transport
Layer Security” (EAP-TLS) and is used to establish a secure connection to the authentication serv
-
er. For the EAP-TLS authentication, it is required to import a client certificate.
If the 802.1X authentication mode “EAP-TLS” is selected, the following additional fields appear:
Identity: Enter the name of the DUETTO device for authentication.
Client certificate: Click on UPLOAD to upload the client certificate issued by the CA.
Client key: Click on UPLOAD to upload the client key matching the client certificate.
Private key password: If required, enter the password matching the client key.
GOOD TO KNOW: What is 802.1X?
As part of the IEEE 802.1 network protocol group, IEEE 802.1X is a port-based network access control
standard. For devices like SIP stations or computers that need to get access to a LAN, WLAN or VLAN
(via 802.1Q), it works as an authentication mechanism between the supplicant, authenticator and authen-
tication server. In detail, the authentication mechanism works as follows:
1. Sending the login data for the local network, the supplicant asks the authenticator for access.
2. Via the authentication server, the authenticator checks whether or not the supplicant has gained
access.
3. If the authentication has been successful, the supplicant will be connected to the LAN and/or the Inter-
net.
ATTENTION: Public key infrastructure
To use the 802.1X authentication mode “EAP-TLS”, an existing public key infrastructure is required.
Reception
Oce
Garage
Authentication
Server
Authenticator
1.
2.
3.
Supplicant
