Control Station Duetto Web interface – Device
2.0/0518 45
box Enable authentication will be shown.
- HTTP Call: The consumer can be triggered by a web browser or third-party application. The
referenced camera stream can be muted during a conversation. The checkbox Enable au
-
thentication will be shown.
- SIP Video (supported by default: 320 x 240 pixels): The consumer is used for a SIP video con-
versation, but cannot be accessed via a web browser or a third-party application. The refer-
enced camera stream can be muted during a conversation.
Enable authentication (optional): Activate this checkbox to enable an authentication at the se-
lected external or internal camera before an HTTP client can request the video stream of the cam-
era. The fields Username and Password will become active.
Username: In this field, enter the user name to gain access to the video stream of the camera (if
required).
Password: In this field, enter the password to gain access to the video stream of the camera
(if required).
Delete: Click on this button to delete the entire configuration of the consumer (the referenced
camera will not be deleted).
Add Consumer: Click on this button to add a new consumer.
➥ Click on the button Save to save the settings.
ATTENTION: Configuration of a call via HTTP
Only one consumer can be configured as the type “SIP Video” or “HTTP Call”!
If there is more than one consumer with the type “HTTP Surveillance” for the same camera
number, the consumer with the highest resolution / FPS setting will be displayed!
