Engineer Menu 2-5 Engineering Manual
98
indicate that the alarm has been reset (this is not the same event as silencing the
external sounders).
2 – Fast Format
Choose whether to transmit 8 or 16 channels of data if using the Fast Format. The data
transmitted by each channel is determined by the Digi On Board output programming
(page 41).
3 – Line Fault
You can use this option to enable or disable monitoring of line faults on the telephone
line to the ARC. Enabling line fault monitoring activates outputs of type PSTN Line Fault
(page 44) when a line fault occurs.
Option 2-5-2-6 – CID/SIA Reporting Level
CID/SID Report 2
Intermediate
[
1234567890123456
1234567890123456
DigiCom 6
CID/SIA Reports
CID/SIA Report 1
Full
[
|
e.g.
To select option:
Press or
"
"
|¬
to scroll, or
Press the hot key (1-5)
1. SELECT REPORTING
LEVEL
Press to save changes and continue
[
This option is not available for M550 and M750 panels.
If you are using an Contact ID or SIA communications format, choose Full, Intermediate,
Summary, Basic or Custom to specify the types of events to transmit to the ARC. Please refer to
page 93 or 94 for further information. You should use the Custom option only if you have used
the Downloader software to specify which events to communicate to the ARC.
Option 2-5-3: Starting a Call Back
This option is not available for M550 and M750 panels.
You can use this option to initiate a connection over the telephone line to a remote site that is
running the Downloader software. Once the communication link is established, the remote site
can upload data and change settings in the control panel.
You can choose one of four call-back numbers (telephone numbers) to call. The call-back
numbers can be set up in Engineer option 2-5-1-4 (page 89).
An alternative method of making a connection between the panel and Downloader PC
is to set the access mode (page 88) to Unattended or Secure Call Back. This allows the
panel to respond to calls that have originated from the remote site.
