Engineer Menu 1-5 Engineering Manual
62
Option 1-5-3: Defining Time Switches
Timers 3
Time Switches
Time Switch 1
e.g.
Time Switch 2
Time Switch 2
On (1) 00:00
Time Switch 2
On (2) >00:00
[
[
[
|
e.g.
X
To select the time switch to set up:
Press or
"
"
|¬
to scroll, or
Press the hot key (1 to 4)
1. SELECT TIME SWITCH
Each time switch has three pairs of switch on/off times. For each
of these, you will notice that there is an option to specify the on
time, one to specify the off time and another to specify the days
of operation.
You can manually override a time switch by pressing , then
pressing to toggle its current status.
0
r
You will see a screen similar to the
above if you have chosen to edit an
on/off time. The number in brackets
indicates whether it is the first, second
or third pair of on/off times. Enter the
time in 24-hour format (e.g. 2100 for
9pm), then press .
Press again to set up other parts
of the time switch, or press to exit.
[
[
]
You will see a screen similar to this if you
have chosen to edit days of operation.
The number in the top-left corner indicates
whether it is associated with the first,
second or third pair of on/off times. Press 1
to 7 to toggle days on/off, then press .
Press again to set up other parts of the
time switch, or press to exit.
[
[
]
2. SELECT ON/OFF TIME
OR DAYS TO EDIT
e.g. press 7 times
|
1 Operates On :-
> ..............
This option enables you to define up to three time switches, which can be used to switch
outputs of the alarm system on or off at selected times. The outputs may, for example, control
internal or external lighting or other electrical equipment.
You can define each time switch to have up to three pairs of switch on/off times. You can also
choose the days of the week that each of these operate.
The outputs controlled by the time switches are specified in Engineer option 1-4 (page 50).
The option is also available from User option 2-0-1.
